Overview
As a fishing pontoon boat, the FISHIN’ BARGE® 22 XP3 delivers with fore and aft casting decks, aerated livewells and rod storage—all in a wide, spacious and extremely stable platform.
But, this model is much more than just a fishing boat. With three 26”-diameter multichambered logs, deck underpinning and up to 200 horsepower behind it, the FISHIN’ BARGE 22 XP3 packs the performance you need for cruising and watersports (just add the optional ski tower!).
Whether fishing or cruising, this is still a SUN TRACKER® pontoon boat, which means you’re also getting plenty of playpen space, seating, storage and comfort for everyone to enjoy all day long.
Specifications
| Length | 7.37 m |
| Deck Length | 6.73 m |
| Deck Width | 2.59 m |
| Max. Recommended HP | 200 HP |
| Fuel Capacity | 196.82 l |
| Pontoon Log Length | 6.78 m |
| Pontoon Log Diameter | 66.04 cm |
| Pontoon Log Material | 0.100 5052 marine alloy |
| Max. Person Capacity | 11 persons |
| Max. Person Weight | 714.41 kg |
| Max. Person, Motor & Gear Weight | 1065.94 kg |
| Interior Depth | 66.04 cm |
| Average Dry Weight | 1306.35 kg |
| Average Package Weight | 2211.26 kg |
| Package Height | 2.79 m |
| Package Width | 2.59 m |
| Towing Length | 9.86 m |
| Storage Length | 9.86 m |
Features
COMFORT, CONVENIENCE & PEACE OF MIND
- 10+LIFE™ Limited Lifetime Warranty
- NMMA® certified
- 10′ (3.05 m) SureShade® powered Bimini top w/push-button stow & deploy, LED courtesy lights & protective boot (Bimini top will be Black w/Black or Charcoal fencing colors & will be Sand w/Caribou, Copper Red or Indigo Blue fencing colors)
- Storage pockets in Bimini top
- Nylon gate latches & heavy-duty hinges that open inward
- Port & starboard LED navigation lights
- Bimini-mounted anchor/navigation light
- Mooring eye on starboard side for tie off
- Four 4.5″ (11.43 cm) fold-down mooring cleats
- Motor-stop safety lanyard
- Fire extinguisher
- Horn
LIVEWELL SYSTEM
- Bow port 16-gal. (60.57 L) rotomolded & aerated livewell w/shutoff valve & composite lid w/ruler
- Aft port 16-gal. (60.57 L) aerated livewell w/removable bait bucket & shutoff valve
CONSOLE
- Deluxe soft-touch sport steering wheel
- Tilt hydraulic steering
- Wraparound sport console shroud & tinted, removable windscreen
- Below-console cooler/storage space w/door & integrated pouch
- Small items tray
- Drink holders
- Built-in footrest w/non-skid pad
-
AM/FM Bluetooth®-capable stereo head unit w/integrated low voltage alarm & 2
NEW
upholstery speakers - USB/3.5 mm auxiliary input ports on console for direct stereo connection
- Tachometer, trim meter/speedometer & fuel & hour gauges
- Lighted rocker switches w/bilge switch
- Ergonomically positioned Mercury® binnacle control box w/trim
- 12V outlet
- Dark console color
INTERIOR
- The patented STOW MORE™ system features an added compartment in the seat back for increased storage
- Large bow port rotomolded box w/livewell, ruler, drink holders & lid
- Large bow starboard rotomolded box w/storage, ruler, drink holders & lid w/room for 24V total battery capacity
- Clam-shell fishing chairs constructed w/all-composite seat frames w/heavy-duty 2-3/8″ (6 cm) diameter pedestals
- Bow fishing deck w/2 removable folding fishing chairs
- Bow rail-mounted vertical rod & tool holders
- Forward-console couch w/STOW MORE™ system & lockable underseat storage
-
88″ (2.24 m) long, 23″ (58.42 cm) deep lighted in-floor storage compartment w/bilge pump in center log &
NEW
spaghetti mat - Aft L-lounge w/STOW MORE™ system & underseat storage
- High-back swiveling helm bucket seat, reclining & w/self-leveling arms
- Rear-facing tackle storage in aft L-lounge
- Aft rail-mounted vertical rod & tool holders
- Aft fishing deck w/2 removable folding fishing chairs
- Molded aft starboard lockable rod box for 6 rods to 7′ 6″ (2.29 m) w/lid, rod tube holders & organizer
- Receptacle for optional ski tow pylon
- Woven 16-oz. (.45 kg) marine-grade flooring throughout
- Marine-grade, UV-resistant, top-coated upholstery w/26-oz. (.74 kg) base material & multiple densities of foam
- Movable drink holder/armrest
- Removable table w/padded insert, 4 molded-in drink holders & 2 pedestal base locations
PERFORMANCE
- XP3 performance package – strakes on inboard side of outer logs & both sides of center tube
- Nose cone & motor pod wave/spray deflectors for a drier ride
- Factory-matched aluminum propeller
CONSTRUCTION & EXTERIOR
-
Color: Charcoal or
NEW
Indigo Blue fencing - Exterior styling w/XP3 graphics package
- Plasma & laser cutters & robotic welding help ensure precise fit & finish throughout
- Rotomolded couches & backs for furniture w/Diamante Pepper accent
- Fishing seats w/Diamante Pepper accent
- Heavy-duty bow U-channel reinforcement behind deck trim
- Three 26″ (66.04 cm) diameter XP3 high-performance multichambered pontoon logs w/welded-on lifting strakes & internal bracing for additional strength
- 1-piece full-length M-bracket deck supports
- Protective exoskeleton rail & panel system for durability & a quieter ride
- High-sheen fence finish for long-lasting good looks
- 1-1/4″ (3.18 cm), .090″ (.23 cm) thick anodized aluminum fence rails w/decorative styling
- Factory-installed underpinning (under-deck shielding) for improved performance
- Extruded anodized aluminum deck edging w/polished aft corner covers
- All-welded, all-aluminum extended motor pod w/built-in EPA-compliant fuel system
- Stainless or coated corrosion-resistant fasteners
- Pressure-treated 3/4″ (1.91 cm) deck w/Limited Lifetime Warranty
- Full-width heavy-duty extruded Z-bar deck supports that are thru-bolted to M-brackets
- Elevated fence panels for deck drainage & ventilation
- Sound- & vibration-deadening fence insulation for a quiet ride
- Box-beam all-aluminum transom for strength & longevity
- Port wheelchair-access gate
-
Rear boarding platform w/
NEW
4-step telescoping boarding ladder & grab rails
ELECTRICAL
- 500 GPH (1892.71 LPH) Ultima auto bilge pump
- Interior courtesy lighting
- Battery disconnect switch
- Easy-access marine-grade automotive-style fuse panel w/latching fuse block door
- Protective abrasion-resistant wire wrap
- Water-resistant connectors
